Compact Structure Pneumatic Flashing Dryer Pressed By Dural Screen

After drying, the commercial pulp board can increase the turnover time and transportation. It is a reasonable choice for paper mills to build overseas pulp bases. Flash drying is an advanced drying form with high efficiency and energy saving. After entering the air duct, the fluffy wet pulp will be suspended under the hot air flow, and will conduct heat and mass transfer quickly, so that the moisture will vaporize instantaneously.

Material

Stainless steel, carbon steel

Product features

Compact structure, small floor area of production line and low investment cost

High drying efficiency, easy transportation and storage of finished products;

High energy efficiency of production line, low investment, low operation and maintenance cost

Application

It is suitable for the drying of pulp with poor wet strength, such as chemi-machanical pulp and mechanical pulp.

Working principle

When the wet pulp is dried, it is first treated by a fuzzer to fully disperse the pulp and fluff the fiber to obtain the maximum specific surface area, and then sent to the drying duct, where it is suspended in the hot air flow at 150~300 ℃. After 3~5 seconds of drying, the moisture is rapidly evaporated, and finally enters the cyclone separator to separate the hot and humid air. The dryness of the wet pulp can be increased from 40% to 80% by this way, So as to extend the turnover time, reduce the transportation cost and meet the needs of pulping.

Our services

Pre-sale service

1. Provide customization: With over 20 years of customization experience, we are able to customize the machine according to your requirements according to output, site area and structure.
2. Project planning and design service.
3. 24-hour online consulting service.

After-sales service

1. Provide 1 year complete warranty and maintenance service. Discount on spare parts purchase after one year.
2. 24-hour online guidance and commissioning service.
3. Provide training services.
